PRODUCT DETAILS

Description

Base PoE is an M5 Base that implements a W5500 Ethernet controller chip with PoE module, which provides Hardwired TCP/IP embedded Ethernet control to facilitate easier internet connection to embedded systems. W5500 integrates TCP/IP protocol stack, 10/100M Ethernet data link layer (MAC) and physical layer (PHY).This base supports RS485 / RS232 communication and can be used as an Ethernet to serial port server. It is specifically designed for industrial applications. PoE (Power over Ethernet) technology is supported. Through the built-in PoE module, power can be directly supplied to the base through PoE hub / switch without a separate power supply. It comes with a couple of HT3.96 connectors, metal rail and magnet discs for easy installation. The 6 pins of the HT3.96 connector are spare, you can wire them up with an RS485 or RS232 adapter board as you like.

This product is EOL now.

Product Features

• Support PoE IEEE802.3 AF
• DC input supply voltage: 9-24V
• Ethernet access
• HT3.96 port for supporting RS485/RS232 communication
• 8 independent hardware socket simultaneous communication
• Support TCP, UDP, ICMP, IPv4, ARP, IGMP, PPPoE protocols
• Support integrated 10BaseT / 100Base-T Ethernet PHY
• Easy to fixed on the wall

Applications

• Ethernet controller
• Ethernet and RS485/RS232 data forwarding
• Ethernet network node

Include

• 1x PoE Base
• 1x TTL-to-RS485 adapter board
• 1x TTL-to-RS232 adapter board
• 1x pin header 20pin
• 1x metal rails and magnet discs
• 3x HT3.96 terminal
• 2x 3pin
• 1x 4pin
• 10x cold crimp terminal（red Copper Lugs）
• 3x HEX KEY  - 1x 1.5mm  - 1x 2mm  - 1x 2.5mm
• 2x hexagon socket head cap screws M3x28
• 4x hexagon socket tapping screw KA2x4
• 1x countersunk head screw M3x8
